Allied Telesis SDR120-48 Voltage Transformer
VS
Schneider Electric ABT7PDU006B Voltage Transformer
Feature Comparison
Technical details
Technical details
| AC input voltage | 88 - 264 V | 207 - 253 V |
|---|---|---|
| AC input frequency | 47 - 63 Hz | - |
| AC voltage range | 48 - 55 V | - |
| DC voltage range | 124 - 370 V | - |
| Output voltage | 48 V | - |
| International Protection (IP) code | IP20 | IP20 |
| Product colour | Blue, Grey | - |
| Material | Metal | - |
| Output power | 120 W | - |
| Peak power | 180 W | - |
| Efficiency | 90.5% | - |
| Mounting type | DIN rail | - |
| Power protection features | Over voltage, Overheating, Overload | - |
| Housing material | Metal | - |
| Rated voltage | - | 63 VA |
| Certification | - | CE |
| Warranty period | - | 1.5 year(s) |
Operational conditions
Operational conditions
| Operating temperature (T-T) | -25 - 70 °C | -20 - 60 °C |
|---|---|---|
| Operating relative humidity (H-H) | 20 - 95% | 0 - 95% |
| Storage temperature (T-T) | -40 - 85 °C | -40 - 80 °C |
| Storage relative humidity (H-H) | 10 - 95% | - |
Weight & dimensions
Weight & dimensions
| Width | 40 mm | 87 mm |
|---|---|---|
| Depth | 125.2 mm | 115 mm |
| Height | 113.5 mm | 108 mm |
| Weight | - | 1.95 kg |
| Package width | - | 255 mm |
| Package depth | - | 185 mm |
| Package height | - | 116 mm |
| Package weight | - | 2.26 kg |
