LG NeON R Solar Panel
VS
Anker 625 100W Solar Panel
Feature Comparison
Power
Power
| Rated power | 400 W | 100 W |
|---|---|---|
| Maximum system voltage | 1000 V | - |
| MPP Current (NMOT) | 8.62 A | - |
| MPP Voltage (NMOT) | 35.2 V | - |
| Maximum Power (STC) | 400 W | - |
| MPP Current (STC) | 10.76 A | - |
| Short-circuit current (Isc) (STC) | 11.32 A | - |
| Power tolerance (STC) | 3% | - |
| MPP Voltage (STC) | 37.2 V | - |
| Open-circuit voltage (STC) | 43.8 V | - |
| Solar panel voltage | - | 26.5 V |
| Solar panel current | - | 3770 mA |
| USB output voltage | - | 5 V |
| USB output current | - | 3 A |
Features
Features
| Solar cell type | Monocrystalline silicon | - |
|---|---|---|
| Connector type | MC4 | Anderson + DC |
| Product colour | Black | Black |
| Housing material | Tempered glass | - |
| Housing thickness | 2.8 mm | - |
| Frame | Yes | - |
| Frame material | Anodized aluminium | - |
| International Protection (IP) code | IP68 | - |
| Fire-resistant | Yes | - |
| Fire-resistance rating | Class C (UL 790) | - |
| Module fire performance | Type 1 | - |
| Mechanical test load (Front) (Pa/psf) | 5400/113 | - |
| Mechanical test load (Rear) (Pa/psf) | 4000/83.5 | - |
| Cell efficiency (STC) | 22.1% | - |
| Number of bypass diodes | 3 | - |
| Number of cells | 60 | - |
| Cable length | 1.25 m | - |
| Installation type | - | Ground |
| Stackable | - | Yes |
| Water-resistant | - | Yes |
| USB connector type | - | USB Type-A, USB Type-C |
| Cell efficiency | - | 23% |
Packaging content
Packaging content
| Manual | Yes | - |
|---|
Packaging data
Packaging data
| Package width | 1120 mm | - |
|---|---|---|
| Package depth | 1790 mm | - |
| Package height | 1227 mm | - |
Technical details
Technical details
| Temperature coefficient of the open-circuit voltage (Voc) | -0.24 %/°C | - |
|---|---|---|
| Temperature coefficient of the short-circuit current (Isc) | 0.04 %/°C | - |
| Warranty period | 25 year(s) | - |
Operational conditions
Operational conditions
| Operating temperature (T-T) | -40 - 85 °C | -20 - 60 °C |
|---|
Weight & dimensions
Weight & dimensions
| Width | 1042 mm | 1446 mm |
|---|---|---|
| Depth | 1740 mm | 45 mm |
| Height | 40 mm | 525 mm |
| Weight | 18.5 kg | 5 kg |
| Folded width | - | 52.5 cm |
| Folded depth | - | 8.5 cm |
| Folded height | - | 47 cm |
| Unfolded width | - | 144.6 cm |
| Unfolded depth | - | 4.5 cm |
| Unfolded height | - | 52.5 cm |
