Samsung VH55R-R 55-inch LCD Video Wall Display
VS
Samsung VM55C-E 55-inch 4K UHD Video Wall Display
Feature Comparison
Display
Display
| Display technology | LCD | LCD |
|---|---|---|
| Display diagonal | 139.7 cm (55") | 139.7 cm (55") |
| Display resolution | 1920 x 1080 pixels | 1920 x 1080 pixels |
| HD type | Full HD | Full HD |
| Panel type | IPS | IPS |
| Pixel pitch | 0.63 x 0.63 mm | 0.63 x 0.63 mm |
| Display brightness | 500 cd/m² | 500 cd/m² |
| Contrast ratio (typical) | 1100:1 | 1000:1 |
| Contrast ratio (dynamic) | 500000:1 | 100000:1 |
| Response time | 0.008 s | 0.008 s |
| Viewing angle, horizontal | 178° | 178° |
| Viewing angle, vertical | 178° | 178° |
| Horizontal scan range | 57.3 - 70 kHz | 57.3 - 70 kHz |
| Vertical scan range | 47 - 63 Hz | 47 - 63 Hz |
| Haze rate | 28% | 28% |
| Colour gamut | 72% | 72% |
| Operating hours (hours/days) | 24/7 | 24/7 |
| Aspect ratio | - | 16:9 |
| Pixel frequency | - | 78 MHz |
| Display diagonal (metric) | - | 138 cm |
Design
Design
| Placement supported | Indoor | Indoor |
|---|---|---|
| Orientation | Horizontal/Vertical | Horizontal/Vertical |
| Bezel width (side) | 0.44 mm | - |
| Bezel width (top) | 0.44 mm | - |
| Bezel width (bottom) | 0.44 mm | - |
| VESA mounting | Yes | Yes |
| Panel mounting interface | 600 x 400 mm | 600 x 400 mm |
| Product colour | Black | Black |
| Panel colour | Black | - |
| Wall mountable | - | Yes |
Ports & interfaces
Ports & interfaces
| HDMI ports quantity | 2 | 2 |
|---|---|---|
| HDMI version | 2.0 | 2.0 |
| DVI port | Yes | Yes |
| DisplayPorts quantity | 1 | 1 |
| DisplayPort version | 1.2 | 1.2 |
| Ethernet LAN | Yes | Yes |
| Ethernet LAN (RJ-45) ports | 1 | 1 |
| RS-232 input ports | 1 | 1 |
| RS-232 output ports | 1 | 1 |
| RS-232C | Yes | - |
| USB port | Yes | Yes |
| USB ports quantity | 1 | 1 |
| HDCP | Yes | Yes |
| HDCP version | 2.2 | 2.2 |
| IR input ports quantity | 1 | 1 |
| Audio input | Yes | Yes |
| Audio output | Yes | Yes |
| HDMI input ports quantity | - | 1 |
| DVI-D ports quantity | - | 1 |
| DisplayPorts in | - | 1 |
| Video out | - | Yes |
Power
Power
| Power consumption (typical) | 270 W | 220 W |
|---|---|---|
| Power consumption (sleep) | 0.5 W | 0.5 W |
| Energy efficiency class (SDR) | G | - |
| Energy consumption (SDR) per 1000 hours | 165 kWh | - |
| AC input voltage | 100 - 240 V | - |
| AC input frequency | 50 - 60 Hz | - |
Operational conditions
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C | 0 - 40 °C |
|---|---|---|
| Operating relative humidity (H-H) | 10 - 80% | 10 - 90% |
Sustainability
Sustainability
| Certification | FCC (USA) Part 15, Subpart B Class A CE (Europe) : EN55022:2006+A1:2007 EN55024:1998+A1:2001+A2:2003 VCCI (Japan) : VCCI V-3 /2010.04 Class A KCC/EK (Korea) : Tuner : KN13 / KN20 Tunerless : KN22 / KN24 BSMI (Taiwan) : CNS13438 (ITE EMI) Class A / CNS13439 (AV EMI) / CNS14409 (AV EMS) / CNS14972 (Digital) C-Tick (Australia) : AS/NZS CISPR22:2009 CCC(China) :GB9254-2008 GB17625.1-2012 GOST(Russia/CIS) : GOST R 51317 Series, GOST 22505-97 EN55022:2006+A1:2007 EN55024:1998+A1:2001+A2:2003 | - |
|---|---|---|
| Sustainability compliance | - | Yes |
Weight & dimensions
Weight & dimensions
| Width | 1211 mm | 1212.2 mm |
|---|---|---|
| Depth | 69.9 mm | 70.4 mm |
| Height | 681.7 mm | 683 mm |
| Weight | 16.8 kg | 19.5 kg |
Packaging data
Packaging data
| Package width | 1414 mm | 1398 mm |
|---|---|---|
| Package depth | 257 mm | 257 mm |
| Package height | 844 mm | 844 mm |
| Package weight | 25.1 kg | 27.1 kg |
