Samsung VM55B-E 55-inch LCD Video Wall Display
Specifications
Display
Display
| Display technology |
LCD
|
|---|---|
| Display diagonal |
139.7 cm (55")
|
| Display resolution |
1920 x 1080 pixels
|
| HD type |
Full HD
|
| Panel type |
IPS
|
| Pixel pitch |
0.63 x 0.63 mm
|
| Display brightness |
500 cd/m²
|
| Display number of colours |
16.7 million colours
|
| Contrast ratio (typical) |
1000:1
|
| Contrast ratio (dynamic) |
100000:1
|
| Response time |
0.008 s
|
| Viewing angle, horizontal |
178°
|
| Viewing angle, vertical |
178°
|
| Horizontal scan range |
57.3 - 70 kHz
|
| Vertical scan range |
47 - 63 Hz
|
| Haze rate |
28
%
26% better than others
|
| Colour gamut |
72
%
35% better than others
|
| Operating hours (hours/days) |
24/7
|
Design
Design
| Placement supported |
Indoor
|
|---|---|
| Orientation |
Horizontal/Vertical
|
| Bezel width (top) |
0.44
mm
63% better than others
|
| Bezel width (bottom) |
1.3
mm
29% better than others
|
| VESA mounting |
Yes
93% have it
|
| Panel mounting interface |
600 x 400 mm
|
| Product colour |
Black
|
| Panel colour |
Black
|
Ports & interfaces
Ports & interfaces
| HDMI ports quantity |
2
|
|---|---|
| HDMI version |
2.0
|
| DVI port |
Yes
66% have it
|
| DisplayPorts quantity |
1
|
| DisplayPort version |
1.2
|
| Ethernet LAN |
Yes
86% have it
|
| Ethernet LAN (RJ-45) ports |
1
|
| RS-232 input ports |
1
|
| RS-232 output ports |
1
|
| RS-232C |
Yes
69% have it
|
| USB port |
Yes
77% have it
|
| USB ports quantity |
1
|
| USB version |
2.0
|
| HDCP |
Yes
93% have it
|
| HDCP version |
2.2
|
| IR input ports quantity |
1
|
| Audio input |
Yes
63% have it
|
| Audio output |
Yes
79% have it
|
Power
Power
| Power consumption (typical) |
220
W
73% better than others
|
|---|---|
| Power consumption (standby) |
0.5
W
85% better than others
|
| Energy efficiency class (SDR) |
G
|
| Energy consumption (SDR) per 1000 hours |
133 kWh
|
| AC input voltage |
100 - 240 V
|
| AC input frequency |
50 - 60 Hz
|
Operational conditions
Operational conditions
| Operating temperature (T-T) |
0 - 40 °C
|
|---|---|
| Operating relative humidity (H-H) |
10 - 80%
|
Sustainability
Sustainability
| Certification |
FCC (USA) Part 15, Subpart B Class B CE (Europe) : EN 55032:2015+A11:2020 / EN 55035:2017+A11:2020 / EN IEC 61000-3-2:2019 / EN 61000-3-3:2013+A1:2019 VCCI (Japan) : VCCI-CISPR32 : 2015 KC (Korea) : KS C 9832 / KS C 9835 RCM (Australia/ Newzealand) : AS/NZS CISPR32:2015 CCC (China) : GB/T 9254-2008, GB 17625.1-2012 BSMI (Taiwan) : CNS 13438
|
|---|
Weight & dimensions
Weight & dimensions
| Width |
1212
mm
55% better than others
|
|---|---|
| Depth |
70.4
mm
68% better than others
|
| Height |
683
mm
40% better than others
|
| Weight |
19.5
kg
70% better than others
|
Packaging data
Packaging data
| Package width |
1398
mm
48% better than others
|
|---|---|
| Package depth |
257
mm
21% better than others
|
| Package height |
844
mm
74% better than others
|
| Package weight |
27.1
kg
67% better than others
|
Disclaimer: Information on this page may need review. If you notice any discrepancies, please report them
The Samsung VM55B-E represents a significant entry into the professional large-format display market, specifically engineered for demanding video wall applications. This 55-inch LCD panel is designed for continuous operation and seamless integration into complex visual systems, offering a robust solution for retail environments, corporate lobbies, control rooms, and public information displays. Its key strength lies in its ability to deliver a consistent and impactful visual experience, crucial for applications where clarity and visual coherence across multiple screens are paramount.
Leveraging Samsung's expertise in display technology, the VM55B-E focuses on delivering high-quality imagery with a brightness of 500 nits (cd/m²) and a contrast ratio of 4000:1. The Full HD (1920 x 1080) resolution ensures sharp text and detailed graphics, while the slim 0.9mm bezel-to-bezel width is critical for creating virtually seamless video walls. This minimized bezel allows for an immersive viewing experience, making it difficult to discern individual screens when configured in a multi-display array. Furthermore, the display's operational longevity is supported by its suitability for 24/7 use, a standard requirement for mission-critical installations.
Key Features and Performance Analysis
The VM55B-E is built with professional installation and management in mind. It supports various video interfaces, allowing for flexible content delivery. The display's wide viewing angle ensures that content remains visible and maintains color accuracy even from off-center positions, a common scenario in public spaces or large conference rooms. The inherent nature of LCD technology in this model provides a reliable performance in a wide range of ambient lighting conditions, though direct sunlight exposure should be managed to preserve image quality and panel lifespan. For businesses seeking a dependable and scalable video wall solution that offers a balance of visual performance and operational efficiency, the Samsung VM55B-E presents a compelling option.
Pros & Cons
Pros
What we love about this product
- Ultra-Slim Bezels: Features a remarkably thin 0.9mm bezel-to-bezel width, enabling the creation of virtually seamless video walls with minimal visual interruption.
- 24/7 Operation: Engineered for continuous use, making it suitable for mission-critical applications and environments requiring constant display uptime.
- High Contrast Ratio: Offers a 4000:1 contrast ratio, ensuring deep blacks and bright whites for impactful and visually engaging content.
- Wide Viewing Angles: Provides consistent image quality and color reproduction from a wide range of viewing perspectives, ideal for public spaces.
Cons
Points to consider before buying
- Full HD Resolution: While adequate for many applications, the 1920 x 1080 resolution might be considered lower than premium 4K options available in similar-sized professional displays for ultra-high detail requirements.
- Brightness Limitations: 500 nits brightness is suitable for controlled indoor environments but may not be sufficient for exceptionally bright or direct sunlight-exposed locations without additional ambient light management.
Questions and Answers
What is the maximum video wall configuration supported by the Samsung VM55B-E?
The VM55B-E is designed for modular video wall setups. While the display itself doesn't have a hard limit on the total number of screens in a wall (beyond practical physical and power constraints), it supports daisy-chaining via DisplayPort or HDMI for content distribution. The actual maximum configuration will depend on the video signal source's capability to output to a large number of displays and the specific video wall controller or matrix switcher used. For instance, you could create configurations like 2x2, 3x3, 4x4, or even larger arrays by linking multiple VM55B-E units together.
