Barco ClickShare C-5 Wireless Presentation System
VS
BenQ InstaShow WDC30 Wireless Presentation System
Feature Comparison
Design
Design
| Form factor | Dongle | Desktop |
|---|---|---|
| Product colour | Black | Black |
| LED indicators | Yes | Yes |
| Cable lock slot | Yes | - |
| Cable lock slot type | Kensington | - |
| Certification | FCC, CE | - |
Features
Features
| Maximum resolution (HDMI) | 3840 x 2160 pixels | - |
|---|---|---|
| Supported video modes | 2160p | 720p, 1080p |
| Supported video streaming resolutions | 4096 x 2160 | - |
| AirPlay mirroring | Yes | - |
| Maximum frame rate | 30 fps | 60 fps |
| Miracast | Yes | - |
| Number of simultaneously connected devices (max) | 32 | 64 |
| Smartphone/tablet remote support | Yes | - |
| Supported graphics resolutions | - | 800 x 600 (SVGA), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080) |
| Security updates end date | - | 31/12/2025 |
Management features
Management features
| Web-based management | Yes | - |
|---|---|---|
| On/off switch | Yes | - |
Network
Network
| Wi-Fi standards | 802.11a, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
|---|---|---|
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) | Wi-Fi 6 (802.11ax) |
| Frequency band | 2.4 / 5 GHz | 2.4 / 5 GHz |
| Dual-band | Yes | Yes |
| Ethernet LAN | Yes | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s | 10,100 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n, IEEE 802.15.1 | - |
| Security algorithms | 802.1x RADIUS, WPA2-PSK | 128-bit AES, WPA2, WPA2-PSK, WPA3 |
| Maximum operating distance | 30 m | 30 m |
| Wi-Fi data rate (max) | - | 1750 Mbit/s |
| Cabling technology | - | 10/100Base-T(X) |
Ports & interfaces
Ports & interfaces
| Interface | HDMI | HDMI |
|---|---|---|
| Number of HDMI outputs | 1 | 2 |
| HDMI version | 1.4b | 2.0 |
| Ethernet LAN (RJ-45) ports | 1 | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 | - |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 | - |
| DC-in jack | Yes | Yes |
| USB 2.0 ports quantity | - | 1 |
| Audio (L/R) out | - | 1 |
Power
Power
| Power source type | AC | DC |
|---|---|---|
| Input voltage | 110 / 220 V | - |
| Power consumption (max) | 24 W | 12 W |
| Power consumption (typical) | 10 W | - |
| Output voltage | - | 12 V |
| Output current | - | 3.33 A |
System requirements
System requirements
| Windows operating systems supported | Windows 10, Windows 11, Windows 8, Windows 8.1 | Yes |
|---|---|---|
| Mac compatibility | Yes | Yes |
| Mac operating systems supported | Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur | - |
| Mobile operating systems supported | Android 10.0, Android 11.0, Android 12.0, Android 9.0, iOS 12, iOS 13, iOS 14.5, iOS 15 | - |
Operational conditions
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C | 0 - 40 °C |
|---|---|---|
| Operating relative humidity (H-H) | 0 - 85% | 10 - 80% |
| Storage temperature (T-T) | -20 - 60 °C | -10 - 60 °C |
| Storage relative humidity (H-H) | 0 - 90% | 5 - 90% |
Weight & dimensions
Weight & dimensions
| Width | 135 mm | - |
|---|---|---|
| Depth | 135 mm | - |
| Height | 34 mm | - |
| Weight | 900 g | 1.73 kg |
| Package width | - | 447 mm |
| Package depth | - | 720 mm |
| Package height | - | 177 mm |
| Package weight | - | 11.9 kg |
Packaging content
Packaging content
| Quick start guide | Yes | Yes |
|---|---|---|
| AC adapter included | - | Yes |
| Cables included | - | HDMI |
Logistics data
Logistics data
| Harmonized System (HS) code | 85176990 | 8517620000 |
|---|---|---|
| Country of origin | - | China |
| Products per pallet | - | 144 pc(s) |
Technical details
Technical details
| Compliance certificates | CE, Federal Communications Commission (FCC) | - |
|---|
Antenna
Antenna
| Antenna type | - | External |
|---|---|---|
| Antenna gain level (max) | - | 5 dBi |
| Antennas quantity | - | 4 |
