| Display diagonal |
190.5 cm (75")
|
2.18 m (86")
|
| Display brightness |
450 cd/m²
|
400 cd/m²
|
| Display resolution |
3840 x 2160 pixels
|
3840 x 2160 pixels
|
| Anti-glare screen |
Yes
|
Yes
|
| HD type |
4K Ultra HD
|
4K Ultra HD
|
| Panel type |
IPS
|
LCD
|
| Native aspect ratio |
16:9
|
16:9
|
| Contrast ratio (typical) |
1200:1
|
1200:1
|
| Contrast ratio (dynamic) |
50000:1
|
5000:1
|
| Response time |
8 ms
|
8 ms
|
| Touchscreen |
Yes
|
Yes
|
| Touch technology |
Multi-touch
|
Multi-touch
|
| Touchscreen type |
Infrared
|
-
|
| Number of simultaneous touchpoints |
50
|
33
|
| Touch system response time |
2.5 ms
|
10 ms
|
| Colour gamut |
72%
|
-
|
| Working area |
1649.7 x 927.9 mm
|
1895.04 x 1065.96 mm
|
| Surface material |
Tempered glass
|
-
|
| Low Blue Light technology |
Yes
|
-
|
| Hardness |
9H
|
9H
|
| Operating system installed |
Android
|
Android
|
| Operating system version |
15
|
9
|
| Built-in processor |
Yes
|
Yes
|
| Processor architecture |
ARM Cortex A78 + ARM Cortex A55
|
ARM Cortex-A73
|
| Processor cores |
8
|
4
|
| Maximum internal memory |
128 GB
|
32 GB
|
| RAM capacity |
8 GB
|
4 GB
|
| Graphics card family |
ARM
|
-
|
| Graphics card |
Mali-G57 MC5
|
-
|
| Built-in speaker(s) |
Yes
|
Yes
|
| Number of built-in speakers |
2
|
2
|
| Speaker power |
20 W
|
30 W
|
| Built-in subwoofer |
Yes
|
Yes
|
| Subwoofer RMS power |
16 W
|
15 W
|
| Built-in microphone |
Yes
|
Yes
|
| Number of microphone arrays |
8
|
8
|
| Built-in projector |
No
|
No
|
| Wi-Fi |
Yes
|
Yes
|
| Top Wi-Fi standard |
Wi-Fi 6 (802.11ax)
|
-
|
| Bluetooth |
Yes
|
-
|
| Bluetooth version |
5.2
|
-
|
| Ethernet LAN |
Yes
|
Yes
|
| Near Field Communication (NFC) |
Yes
|
-
|
| Interface |
HDMI
|
HDMI
|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
7
|
-
|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B Touch ports quantity |
3
|
-
|
| USB 2.0 ports quantity |
1
|
2
|
| USB connector type |
USB Type-A, USB Type-B, USB Type-C
|
USB Type-A, USB Type-B, USB Type-C
|
| HDMI ports quantity |
5
|
3
|
| USB Type-C ports quantity |
4
|
1
|
| HDMI version |
2.0
|
2.0
|
| HDMI output ports quantity |
1
|
1
|
| USB Power Delivery (USB PD) |
Yes
|
Yes
|
| USB Power Delivery up to |
100 W
|
65 W
|
| DisplayPort version |
1.2a
|
-
|
| DisplayPorts quantity |
1
|
1
|
| Ethernet LAN (RJ-45) ports |
2
|
2
|
| VGA (D-Sub) ports quantity |
1
|
1
|
| Line-in |
Yes
|
-
|
| OPS slot |
1
|
1
|
| S/PDIF out port |
Yes
|
Yes
|
| Microphone connectivity |
3.5 mm
|
-
|
| Headphone connectivity |
3.5 mm
|
3.5 mm
|
| RS-232 ports |
1
|
1
|
| Product colour |
Black
|
Black
|
| VESA mounting |
Yes
|
Yes
|
| Panel mounting interface |
800 x 400 mm
|
800 x 600 mm
|
| Wall mountable |
Yes
|
Yes
|
| Mean time between failures (MTBF) |
50000 h
|
50000 h
|
| Ambient light sensor |
Yes
|
-
|
| Infrared sensor |
Yes
|
-
|
| Humidity sensor |
Yes
|
-
|
| PM2.5 sensor |
Yes
|
-
|
| Number of air ionizers |
1
|
-
|
| Motion sensor |
Yes
|
-
|
| Operating hours (hours/days) |
18/7
|
-
|
| Power consumption (typical) |
109.3 W
|
187.9 W
|
| Power consumption (standby) |
0.5 W
|
-
|
| AC input voltage |
100 - 240 V
|
100 - 240 V
|
| AC input frequency |
50/60 Hz
|
-
|
| Operating temperature (T-T) |
0 - 40 °C
|
0 - 40 °C
|
| Operating relative humidity (H-H) |
10 - 90%
|
20 - 80%
|
| Storage temperature (T-T) |
-20 - 60 °C
|
-
|
| Storage relative humidity (H-H) |
10 - 90%
|
-
|
| Width |
1709.4 mm
|
1966.4 mm
|
| Depth |
117.7 mm
|
118.4 mm
|
| Height |
1060.8 mm
|
1204.4 mm
|
| Weight |
52.2 kg
|
71 kg
|
| Package width |
1863 mm
|
2140 mm
|
| Package depth |
205 mm
|
280 mm
|
| Package height |
1155 mm
|
1340 mm
|
| Package weight |
64.5 kg
|
89.1 kg
|
| Quantity per pack |
1 pc(s)
|
1 pc(s)
|
| Manual |
Yes
|
-
|
| Pen tray included |
Yes
|
-
|
| Cables included |
HDMI, USB Type-C, VGA
|
AC, HDMI, USB
|
| Remote control included |
Yes
|
Yes
|
| Mounting kit |
Yes
|
Yes
|
| Stylus included |
Yes
|
Yes
|
| Number of stylus pens |
2
|
-
|
| Sustainability certificates |
ENERGY STAR
|
-
|
| Display number of colours |
-
|
1.07 billion colours
|
| LED backlighting type |
-
|
Direct-LED
|
| Touch resolution |
-
|
32767 x 32767 pixels
|
| Viewing angle, horizontal |
-
|
178°
|
| Viewing angle, vertical |
-
|
178°
|
| Technology |
-
|
Ultrasonic
|
| RAM type |
-
|
DDR4
|
| Ethernet LAN data rates |
-
|
10,100,1000 Mbit/s
|
| HDCP |
-
|
Yes
|
| HDCP version |
-
|
2.2
|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity |
-
|
4
|
| USB 2.0 Type-B Touch ports quantity |
-
|
2
|
| Audio output |
-
|
1
|
| Certification |
-
|
cTUVus, FCC, EPEAT, Mexico coc, Mexico Energy, RoHS, Energy Star 8, CEC, EMC/CE, CB, RoHS & DOC, REACH, WEEE, ErP. EEI, RCM, BIS, PSE, VCCI, CCC, CECP, BSMI
|
| Power consumption (off) |
-
|
0.5 W
|
| Battery type |
-
|
AAA
|
| Number of batteries supported |
-
|
2
|
| USB cable length |
-
|
1.5 m
|
| Batteries included |
-
|
Yes
|
| Mounting brackets included |
-
|
Yes
|
| Quick start guide |
-
|
Yes
|
