Dell PERC H710p RAID Controller
VS
Dell PERC H310 RAID Controller PCI Express x8 2.0 6 Gbit/s
Feature Comparison
Ports & interfaces
Ports & interfaces
| Supported storage drive interfaces | SAS, Serial ATA | SAS, Serial ATA |
|---|---|---|
| Host interface | PCI Express x8 | PCI Express x8 |
| PCI Express slots version | 2.0 | 2.0 |
| Internal mini-SAS ports | 2 | 2 |
Performance
Performance
| RAID levels | 0, 1, 5, 6, 10, 50, 60 | 0, 1, 5, 10, 50 |
|---|---|---|
| RAID Level Migration | Yes | - |
| Data transfer rate | 6 Gbit/s | 6 Gbit/s |
| SSD support | Yes | Yes |
| Internal memory | 1024 MB | - |
| Internal memory type | DDR3 | - |
| Memory clock speed | 1333 MHz | - |
| Chipset | LSISA2208 | - |
| Number of devices supported | 32 | - |
| Online Capacity Expansion | Yes | - |
| Sustained data transfer rate (native) | - | 600 MB/s |
| Compatible products | - | PowerEdge M520 PowerEdge M620 |
Processor
Processor
| Processor family | PowerPC | - |
|---|---|---|
| Built-in processor | - | LSISAS2008 |
Power
Power
| Voltage | 12 V | +12 V |
|---|
System requirements
System requirements
| Linux operating systems supported | Yes | - |
|---|
Operational conditions
Operational conditions
| Operating temperature (T-T) | 0 - 60 °C | 0 - 65 °C |
|---|---|---|
| Operating relative humidity (H-H) | 10 - 90% | 5 - 90% |
| Storage relative humidity (H-H) | 5 - 95% | 5 - 90% |
| Storage temperature (T-T) | - | -45 - 105 °C |
Weight & dimensions
Weight & dimensions
| Width | 64.4 mm | 167.6 mm |
|---|---|---|
| Height | 167.6 mm | - |
| Depth | - | 64.4 mm |
Other features
Other features
| PCI Card form factor | - | Full-height (low-profile) |
|---|
