Price Comparison
VS
No stores registered at this time
Silverstone St45Sf V3 0 450W
VS
Gamdias Helios E1 500 500W
Feature Comparison
General specifications
General specifications
| Equivalent Name | - | |
|---|---|---|
| Device Design and Dimensions |
Main features
Main features
| Output Power | ||
|---|---|---|
| Modular Structure | Non-Modular | Non-Modular |
| Power Factor Correction (PFC) | Yes, Active PFC | No |
| PFC Amount (Power Factor Correction) | More than 0.9 | - |
| 80Plus Certification Level | - | |
| Power Efficiency |
Connections
Connections
| Input Voltage | ||
|---|---|---|
| Input Current | Max 7 Amps | 3.5 to 7.5 Amps |
| Motherboard Connector | 1 x 24-pin (20+4) | 1 x 24-pin (20+4) |
| Number of SATA Connectors | 3 piece | 5 piece |
| Number of Molex Connectors | 2 x 4-pin | 2 x 4-pin |
| Number of FDD Connectors | 1 piece | 1 piece |
| 12V Output Power | ||
| 5V and 3.3V Output Power | ||
| 12V Output Current | 37.5 ampere (a) | 32 ampere (a) |
| 5V Output Current | 20 ampere (a) | 15 ampere (a) |
| 3.3V Output Current | 20 ampere (a) | 15 ampere (a) |
| 5VSB+ Output Current | 3 ampere (a) | 2.5 ampere (a) |
| 12V- Output Current | 0.3 ampere (a) | 0.3 ampere (a) |
Technical features
Technical features
| Input Frequency Amount | ||
|---|---|---|
| Signal Timing Range | 100 to 500 milliseconds | - |
| Average Nominal Lifetime (MTBF) | 100,000 hours | - |
| Operating Temperature Range | - | |
| Other Technical Features | - |
Aesthetic features
Aesthetic features
| Cooling Mechanism | 92mm fan | 120mm fan |
|---|---|---|
| Size and Dimensions | 63.5 * 100 * 125 millimeter (mm) | 86 * 140 * 150 millimeter (mm) |
| Product Weight | 1.1 kilogram (kg) | - |
| Cable and Connection Specifications | Sleeved/Coated | Sleeved/Coated |
| RGB Lighting Capability | No | No |
| Type and Specifications of Cables | 1 x 24-pin motherboard cable, 30cm long / 1 x 8-pin CPU cable, 40cm long / 1 x 8-pin and 6-pin PCIe cable, 40cm long / 1 x SATA cable, 60cm long / 1 x shared Molex and FDD cable, 30cm long | 1 x 24-pin motherboard cable / 1 x 8-pin CPU cable / 1 x 8-pin PCIe cable / 1 x SATA cable / 1 x shared Molex, FDD, and SATA cable |
Other features
Other features
| Moisture Resistance Level | Usable in humid environments with 20% to 90% humidity / Storable in humid environments with 20% to 95% humidity and temperatures from -40 to 70 degrees Celsius | - |
|---|
Buttons or control keys
Buttons or control keys
| Power Key Support | Yes | Yes |
|---|
Capabilities
Capabilities
| Fanless Mode Support | No | No |
|---|---|---|
| Energy Efficiency Mode (Eco) | No | No |
| Additional Features | - |
Certifications and standards
Certifications and standards
| ATX 12V Standard | Yes, version 2.4 | Yes, Version 2.4 |
|---|---|---|
| Protective Standards |
