TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router

Specifications

WAN connection
WAN connection TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router
Ethernet WAN
Yes
88% have it
DSL WAN
Yes
59% have it
SIM card slot
No
12% do not have it
3G/4G USB modem compatibility
Yes
87% have it
WAN connection type
RJ-45
Wireless LAN features
Wireless LAN features TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router
Wi-Fi band
Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard
Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)
1300 Mbit/s
Wi-Fi standards
802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rate (first band)
1300 Mbit/s
WLAN data transfer rate (second band)
600 Mbit/s
Network
Network TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router
Ethernet LAN
Yes
91% have it
Ethernet LAN interface type
Gigabit Ethernet
Ethernet LAN data rates
10,100,1000 Mbit/s
Cabling technology
10/100/1000Base-T(X)
Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Dynamic DNS (DDNS)
Yes
78% have it
Static route
Yes
85% have it
VPN tunnels quantity
10
65% better than others
VPN Passthrough
Yes
83% have it
VPN support
PPTP, L2TP, IPSec Passthrough
DSL features
DSL features TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router
ADSL
Yes
64% have it
ADSL2
Yes
80% have it
ADSL2+
Yes
57% have it
VDSL2
Yes
83% have it
Ports & interfaces
Ports & interfaces TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router
Ethernet LAN (RJ-45) ports
4
USB port
Yes
74% have it
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
RJ-11 ports quantity
1
DC-in jack
Yes
72% have it
Management features
Management features TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router
Web-based management
Yes
76% have it
Quality of Service (QoS) support
Yes
73% have it
Reset button
Yes
66% have it
WPS push button
Yes
89% have it
Security
Security TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router
Security algorithms
128-bit WEP, 64-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Firewall
Yes
67% have it
Guest access
Yes
72% have it
Access Control List (ACL)
Yes
62% have it
DoS attack prevention
Yes
85% have it
Filtering
Yes
94% have it
MAC address filtering
Yes
94% have it
IP address filtering
Yes
61% have it
URL filtering
Yes
66% have it
Protocols
Protocols TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router
DHCP client
Yes
59% have it
DHCP server
Yes
67% have it
Universal Plug and Play (UPnP)
Yes
72% have it
Management protocols
SSL for TR-069, SNMP v1/2c
Data link protocols
IPv4, IPv6
Supported network protocols
ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC 1483 Routed), Bridge (RFC1483 Bridge), PVC
Design
Design TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router
Product colour
White
Wall mountable
Yes
60% have it
Indication light
Yes
84% have it
LED indicators
Yes
71% have it
On/off switch
Yes
94% have it
Product type
Tabletop router
Certificates
Certificates TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router
Certification
CE, RCM, RoHS
Packaging content
Packaging content TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router
Cables included
DSL, LAN (RJ-45), Phone (RJ-11)
AC adapter included
Yes
93% have it
Quick installation guide
Yes
60% have it
Antenna
Antenna TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router
Antenna design
External
Antenna connector type
RP-SMA
Antenna gain level (max)
3 dBi
Antennas quantity
3
Detachable antenna(s)
Yes
60% have it
Transmit power
0 dBmW
Power
Power TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router
Power source type
AC
Output voltage
12 V
77% better than others
Output current
2.5 A
73% better than others
Operational conditions
Operational conditions TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
5 - 90%
System requirements
System requirements TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router
Linux operating systems supported
Yes
71% have it
Mac operating systems supported
macOS
Windows operating systems supported
Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 98SE, Windows NT, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Weight & dimensions
Weight & dimensions TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router
Width
215.7 mm
77% better than others
Depth
163.7 mm
84% better than others
Height
38.9 mm
59% better than others
Packaging data
Packaging data TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router
Package width
318 mm
17% better than others
Package depth
240 mm
80% better than others
Package height
71 mm
48% better than others
Package weight
1.27 kg
21% better than others
Logistics data
Logistics data TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router
Harmonized System (HS) code
85176990
87% better than others
Other features
Other features TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router
Mobile network connection
Yes
89% have it
WLAN data transfer rates supported
600,1300 Mbit/s
Minimum system requirements
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 Cable / DSL Modem
Input current
3.3 A
43% better than others
Input voltage
12 V
52% better than others
Frequency band
2.4 & 5
Rack mounting
No
16% do not have it
xDSL connection
Yes
77% have it
Disclaimer: Information on this page may need review. If you notice any discrepancies, please report them
Nolan Brooks
Reviewed by
Nolan Brooks Storage Systems Analyst & Network Engineer Versus Wizard

The TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router stands as a robust solution for users seeking a high-performance, all-in-one networking device. Designed to support both VDSL and ADSL connections, this router bridges the gap for those migrating to faster broadband technologies while maintaining compatibility with older ADSL infrastructure. Its AC1900 Wi-Fi standard promises significant speed enhancements over older wireless technologies, crucial for demanding applications like 4K streaming, online gaming, and large file transfers across multiple devices simultaneously.

Beyond its core modem functionality, the AC1900 designation highlights its dual-band wireless capabilities, delivering up to 600Mbps on the 2.4GHz band and 1300Mbps on the 5GHz band, aggregating to a theoretical maximum of 1900Mbps. The inclusion of Gigabit Ethernet ports ensures that wired connections maintain maximum throughput, essential for NAS devices, gaming consoles, and high-speed workstations. This device is engineered for users who prioritize speed, reliability, and a consolidated network setup, aiming to simplify their home or small office network infrastructure without compromising on performance.

Key Features and Performance Analysis

At the heart of the TP-Link AC1900 is its commitment to delivering high-speed internet access and robust wireless coverage. The integrated VDSL2/ADSL2+/ADSL2/ADSL modem offers broad compatibility with various broadband services, simplifying the transition to faster internet plans. Coupled with the AC1900 Wi-Fi, which leverages dual-band technology, users benefit from a more stable and faster wireless experience. The 5GHz band is ideal for bandwidth-intensive activities, minimizing interference, while the 2.4GHz band provides wider coverage for less demanding devices.

The router's performance is further bolstered by its Gigabit Ethernet ports, ensuring that devices connected via cable experience speeds up to 10 times faster than standard Ethernet. This is particularly beneficial for wired backhaul in larger networks or for connecting high-demand devices that require consistent, high-speed connectivity. Advanced QoS (Quality of Service) settings allow users to prioritize traffic, ensuring that critical applications receive the necessary bandwidth. Security features, such as robust WPA/WPA2 encryption and a built-in firewall, are standard, providing a secure network environment. The ease of setup, often facilitated by TP-Link's user-friendly interface, makes it an attractive option for both tech-savvy users and those less familiar with advanced networking configurations.

Pros & Cons

Pros
What we love about this product
    • High-Speed Wireless: Supports AC1900 dual-band Wi-Fi (up to 1900Mbps) for seamless streaming and gaming.
    • Versatile Modem: Integrated VDSL2/ADSL2+/ADSL2/ADSL modem offers broad compatibility with various broadband connections.
    • Gigabit Ethernet: Features multiple Gigabit Ethernet ports for ultra-fast wired network speeds.
    • Advanced QoS: Allows for traffic prioritization to ensure smooth performance for critical applications.
Cons
Points to consider before buying
    • Limited Advanced Features: May lack some of the highly granular control or advanced VPN server capabilities found in dedicated enterprise-grade routers.
    • No USB 3.0: Typically only includes USB 2.0 ports, which can limit file transfer speeds for connected storage devices.
    • Single WAN Port: Primarily designed as an all-in-one modem/router, lacking a separate WAN port for multi-WAN failover setups without additional hardware.
