| Ethernet WAN |
Yes
88% have it
|
|---|---|
| DSL WAN |
Yes
59% have it
|
| SIM card slot |
No
12% do not have it
|
| 3G/4G USB modem compatibility |
Yes
87% have it
|
| WAN connection type |
RJ-45
|
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz)
|
|---|---|
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac)
|
| WLAN data transfer rate (max) |
1300 Mbit/s
|
| Wi-Fi standards |
802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
|
| WLAN data transfer rate (first band) |
1300 Mbit/s
|
| WLAN data transfer rate (second band) |
600 Mbit/s
|
| Ethernet LAN |
Yes
91% have it
|
|---|---|
| Ethernet LAN interface type |
Gigabit Ethernet
|
| Ethernet LAN data rates |
10,100,1000 Mbit/s
|
| Cabling technology |
10/100/1000Base-T(X)
|
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
|
| Dynamic DNS (DDNS) |
Yes
78% have it
|
| Static route |
Yes
85% have it
|
| VPN tunnels quantity |
10
65% better than others
|
| VPN Passthrough |
Yes
83% have it
|
| VPN support |
PPTP, L2TP, IPSec Passthrough
|
| ADSL |
Yes
64% have it
|
|---|---|
| ADSL2 |
Yes
80% have it
|
| ADSL2+ |
Yes
57% have it
|
| VDSL2 |
Yes
83% have it
|
| Ethernet LAN (RJ-45) ports |
4
|
|---|---|
| USB port |
Yes
74% have it
|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2
|
| RJ-11 ports quantity |
1
|
| DC-in jack |
Yes
72% have it
|
| Web-based management |
Yes
76% have it
|
|---|---|
| Quality of Service (QoS) support |
Yes
73% have it
|
| Reset button |
Yes
66% have it
|
| WPS push button |
Yes
89% have it
|
| Security algorithms |
128-bit WEP, 64-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
|
|---|---|
| Firewall |
Yes
67% have it
|
| Guest access |
Yes
72% have it
|
| Access Control List (ACL) |
Yes
62% have it
|
| DoS attack prevention |
Yes
85% have it
|
| Filtering |
Yes
94% have it
|
| MAC address filtering |
Yes
94% have it
|
| IP address filtering |
Yes
61% have it
|
| URL filtering |
Yes
66% have it
|
| DHCP client |
Yes
59% have it
|
|---|---|
| DHCP server |
Yes
67% have it
|
| Universal Plug and Play (UPnP) |
Yes
72% have it
|
| Management protocols |
SSL for TR-069, SNMP v1/2c
|
| Data link protocols |
IPv4, IPv6
|
| Supported network protocols |
ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC 1483 Routed), Bridge (RFC1483 Bridge), PVC
|
| Product colour |
White
|
|---|---|
| Wall mountable |
Yes
60% have it
|
| Indication light |
Yes
84% have it
|
| LED indicators |
Yes
71% have it
|
| On/off switch |
Yes
94% have it
|
| Product type |
Tabletop router
|
| Certification |
CE, RCM, RoHS
|
|---|
| Cables included |
DSL, LAN (RJ-45), Phone (RJ-11)
|
|---|---|
| AC adapter included |
Yes
93% have it
|
| Quick installation guide |
Yes
60% have it
|
| Antenna design |
External
|
|---|---|
| Antenna connector type |
RP-SMA
|
| Antenna gain level (max) |
3 dBi
|
| Antennas quantity |
3
|
| Detachable antenna(s) |
Yes
60% have it
|
| Transmit power |
0 dBmW
|
| Power source type |
AC
|
|---|---|
| Output voltage |
12
V
77% better than others
|
| Output current |
2.5
A
73% better than others
|
| Operating temperature (T-T) |
0 - 40 °C
|
|---|---|
| Storage temperature (T-T) |
-40 - 70 °C
|
| Operating relative humidity (H-H) |
10 - 90%
|
| Storage relative humidity (H-H) |
5 - 90%
|
| Linux operating systems supported |
Yes
71% have it
|
|---|---|
| Mac operating systems supported |
macOS
|
| Windows operating systems supported |
Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 98SE, Windows NT, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
|
| Width |
215.7
mm
77% better than others
|
|---|---|
| Depth |
163.7
mm
84% better than others
|
| Height |
38.9
mm
59% better than others
|
| Package width |
318
mm
17% better than others
|
|---|---|
| Package depth |
240
mm
80% better than others
|
| Package height |
71
mm
48% better than others
|
| Package weight |
1.27
kg
21% better than others
|
| Harmonized System (HS) code |
85176990
87% better than others
|
|---|
| Mobile network connection |
Yes
89% have it
|
|---|---|
| WLAN data transfer rates supported |
600,1300 Mbit/s
|
| Minimum system requirements |
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0
Cable / DSL Modem
|
| Input current |
3.3
A
43% better than others
|
| Input voltage |
12
V
52% better than others
|
| Frequency band |
2.4 & 5
|
| Rack mounting |
No
16% do not have it
|
| xDSL connection |
Yes
77% have it
|
The TP-Link AC1900 Wireless Gigabit VDSL/ADSL Modem Router stands as a robust solution for users seeking a high-performance, all-in-one networking device. Designed to support both VDSL and ADSL connections, this router bridges the gap for those migrating to faster broadband technologies while maintaining compatibility with older ADSL infrastructure. Its AC1900 Wi-Fi standard promises significant speed enhancements over older wireless technologies, crucial for demanding applications like 4K streaming, online gaming, and large file transfers across multiple devices simultaneously.
Beyond its core modem functionality, the AC1900 designation highlights its dual-band wireless capabilities, delivering up to 600Mbps on the 2.4GHz band and 1300Mbps on the 5GHz band, aggregating to a theoretical maximum of 1900Mbps. The inclusion of Gigabit Ethernet ports ensures that wired connections maintain maximum throughput, essential for NAS devices, gaming consoles, and high-speed workstations. This device is engineered for users who prioritize speed, reliability, and a consolidated network setup, aiming to simplify their home or small office network infrastructure without compromising on performance.
At the heart of the TP-Link AC1900 is its commitment to delivering high-speed internet access and robust wireless coverage. The integrated VDSL2/ADSL2+/ADSL2/ADSL modem offers broad compatibility with various broadband services, simplifying the transition to faster internet plans. Coupled with the AC1900 Wi-Fi, which leverages dual-band technology, users benefit from a more stable and faster wireless experience. The 5GHz band is ideal for bandwidth-intensive activities, minimizing interference, while the 2.4GHz band provides wider coverage for less demanding devices.
The router's performance is further bolstered by its Gigabit Ethernet ports, ensuring that devices connected via cable experience speeds up to 10 times faster than standard Ethernet. This is particularly beneficial for wired backhaul in larger networks or for connecting high-demand devices that require consistent, high-speed connectivity. Advanced QoS (Quality of Service) settings allow users to prioritize traffic, ensuring that critical applications receive the necessary bandwidth. Security features, such as robust WPA/WPA2 encryption and a built-in firewall, are standard, providing a secure network environment. The ease of setup, often facilitated by TP-Link's user-friendly interface, makes it an attractive option for both tech-savvy users and those less familiar with advanced networking configurations.
