D-Link 15.4W Gigabit PoE Injector (DGS-1008P/IN)
VS
LevelOne 10/100/1000Mbps Gigabit PoE Injector (PnP-1001)
Feature Comparison
Network
Network
| Ethernet interface type | Gigabit Ethernet | Fast Ethernet |
|---|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s | 10,100 Mbit/s |
| Cabling technology | 10/100/1000 | - |
| Power over Ethernet (PoE) | Yes | Yes |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u | IEEE 802.3, IEEE 802.3u |
Features
Features
| Product colour | White | Black |
|---|---|---|
| Wall mountable | Yes | - |
| Easy to install | Yes | - |
| Plug and Play | Yes | Yes |
| Maximum operating distance | 100 m | - |
| LED indicators | Yes | PoE, Power |
| Pin assignment & polarity | - | 4/5, 7/8 |
Ports & interfaces
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 2 | 2 |
|---|---|---|
| DC-in jack | Yes | - |
Power
Power
| Output current | 0.4 A | 0.6 A |
|---|---|---|
| Power consumption (max) | 19.2 W | 30 W |
| Power over Ethernet (PoE) voltage | - | 52 V |
| AC adapter input voltage | - | 100 - 240 V |
| AC adapter frequency | - | 50/60 Hz |
| Input voltage | - | 52 V |
| Input current | - | 0.8 A |
| Total Power over Ethernet (PoE) budget | - | 30 W |
Certificates
Certificates
| Certification | CE FCC VCCI C-Tick IC | FCC Part 15, CE, RoHS |
|---|
Operational conditions
Operational conditions
| Operating temperature (T-T) | 0 - 50 °C | 0 - 45 °C |
|---|---|---|
| Operating relative humidity (H-H) | 10 - 90% | 5 - 95% |
| Storage temperature (T-T) | -20 - 70 °C | 0 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% | 5 - 95% |
Weight & dimensions
Weight & dimensions
| Width | 62.2 mm | 55 mm |
|---|---|---|
| Depth | 109.8 mm | 35.5 mm |
| Height | 24.5 mm | 173.5 mm |
| Weight | 65 g | 280 g |
Packaging content
Packaging content
| Number of products included | 1 pc(s) | 1 pc(s) |
|---|---|---|
| Power cord included | - | Yes |
| Quick installation guide | - | Yes |
Packaging data
Packaging data
| Package width | 153 mm | 55 mm |
|---|---|---|
| Package depth | 213 mm | 125 mm |
| Package height | 68 mm | 210 mm |
| Package weight | 420 g | 450 g |
| Package length | - | 8 cm |
| Package type | - | Box |
Logistics data
Logistics data
| Shipping (inner) case length | 32.6 cm | - |
|---|---|---|
| Shipping (inner) case width | 23.3 cm | - |
| Shipping (inner) case height | 36 cm | - |
| Shipping (inner) case net weight | 4.26 kg | - |
| Products per shipping (inner) case | 10 pc(s) | - |
| Pallet gross weight (air) | 316.4 kg | - |
| Master (outer) cases per pallet (air) | 60 pc(s) | - |
| Products per pallet (air) | 600 pc(s) | - |
| Pallet gross length | 120 cm | - |
| Pallet gross width | 110 cm | - |
| Pallet height (air) | 194 cm | - |
| Pallet gross weight (sea) | 316.4 kg | - |
| Master (outer) cases per pallet (sea) | 60 pc(s) | - |
| Products per pallet (sea) | 600 pc(s) | - |
| Pallet height (sea) | 194 cm | - |
| Shipping (inner) case gross weight | 4.94 kg | - |
| Harmonized System (HS) code | 85044095 | 85044090 |
| Country of origin | - | China |
