Allied Telesis AT-SBx81GS24a Gigabit Ethernet Switch Module
Allied Telesis AT-SBx81GS24a Gigabit Ethernet Switch Module
No stores registered at this time
Contact Us
Specifications
Network
Network
| Ethernet interface type |
Gigabit Ethernet
|
|---|---|
| Ethernet LAN data rates |
100,1000 Mbit/s
|
| Flow control support |
Yes
90% have it
|
| Networking standards |
IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
|
| Jumbo frames support |
Yes
88% have it
|
| Link aggregation |
Yes
57% have it
|
Optical fiber
Optical fiber
| Fiber optic connector |
SFP
|
|---|
Ports & interfaces
Ports & interfaces
| Fiber ports quantity |
24
31% better than others
|
|---|
Performance
Performance
| Quality of Service (QoS) support |
Yes
69% have it
|
|---|---|
| Service level |
3
|
| Buffer size per port |
3
MB
27% better than others
|
| Queues per port |
8
|
| Access Control List (ACL) |
Yes
85% have it
|
| Security algorithms |
802.1x RADIUS, SSH-2
|
| Compatibility |
Allied Telesis SwitchBlade x8100
|
Power
Power
| Power consumption (typical) |
56.3
W
91% better than others
|
|---|
Operational conditions
Operational conditions
| Operating temperature (T-T) |
0 - 40 °C
|
|---|---|
| Storage temperature (T-T) |
-25 - 70 °C
|
| Operating relative humidity (H-H) |
5 - 90%
|
| Storage relative humidity (H-H) |
5 - 95%
|
| Operating altitude |
0 - 3048 m
|
Certificates
Certificates
| Safety |
UL60950-1, CAN/CSA-C22.2 No. 60950-1-03, EN60950-1, EN60825-1, AS/NZS 60950.1
|
|---|---|
| Electromagnetic compatibility |
EN55022 class A, FCC class A, VCCI class A
|
| Certification |
EN55024, EN61000-3
UL, cUL, TUV
RoHS
|
Weight & dimensions
Weight & dimensions
| Dimensions (WxDxH) |
207 x 313 x 41 mm
|
|---|---|
| Weight |
1.1
kg
39% better than others
|
Logistics data
Logistics data
| Harmonized System (HS) code |
85176990
94% better than others
|
|---|---|
| Country of origin |
Indonesia
|
Disclaimer: Information on this page may need review. If you notice any discrepancies, please report them
The Allied Telesis AT-SBx81GS24a represents a robust and high-performance solution designed for demanding network environments. As a key component within the Allied Telesis x810 series chassis, this Gigabit Ethernet switch module offers a compelling blend of port density, switching capacity, and advanced features tailored for enterprise-level deployments. Its integration into a modular chassis allows for significant scalability and flexibility, enabling organizations to adapt their network infrastructure to evolving bandwidth requirements and application demands without the need for a complete hardware overhaul.
This module is engineered to deliver reliable and efficient network connectivity, making it suitable for a variety of applications, from core network aggregation to high-density access layer deployments. The AT-SBx81GS24a's specification highlights its capability to support high-speed data transfer, crucial for today's bandwidth-intensive applications such as video conferencing, large file transfers, and cloud-based services. Its inclusion within a sophisticated chassis system underscores Allied Telesis' commitment to providing scalable and manageable network solutions for businesses seeking a high-performance, future-proof infrastructure.
Key Features and Performance
The AT-SBx81GS24a is characterized by its 24-port Gigabit Ethernet configuration, providing ample connectivity for numerous end devices. This density is crucial for environments such as large offices, data centers, or campus networks where a high concentration of workstations, servers, or other network-attached devices requires reliable high-speed access. The module is designed to slot into the Allied Telesis SBx8100 chassis, which provides a resilient and expandable foundation for the network edge.
Scalability and Integration
The primary advantage of the AT-SBx81GS24a lies in its modular design. By leveraging the SBx8100 chassis, network administrators can deploy multiple modules to increase port count or add different types of connectivity as needed, facilitating a pay-as-you-grow strategy. This approach minimizes initial investment while ensuring that the network can scale efficiently to meet future demands. The integration capabilities within the Allied Telesis ecosystem also ensure seamless management and interoperability with other Allied Telesis devices, simplifying network administration and maintenance.
Pros & Cons
Pros
What we love about this product
- High Port Density: Offers 24 Gigabit Ethernet ports, ideal for high-demand network environments.
- Modular Design: Integrates with the SBx8100 chassis for scalable and flexible network expansion.
- Enterprise-Grade Performance: Designed for reliable, high-speed data transfer crucial for modern business applications.
- Allied Telesis Ecosystem: Ensures compatibility and simplified management within a broader Allied Telesis network infrastructure.
Cons
Points to consider before buying
- Chassis Dependent: Requires the purchase of the SBx8100 chassis to function, representing an additional upfront cost.
- Limited to Gigabit: Does not natively support higher speeds like 10GbE or 25GbE on these specific ports, which might be a limitation for future-proofing in some core network roles.
