Zyxel NR7101 5G Outdoor Router
VS
TP-Link M7650 LTE-Advanced Cat11 Mobile Wi-Fi Router
Feature Comparison
Design
Design
| Device type | Cellular network router | Cellular network router |
|---|---|---|
| Product colour | White | Black, Grey |
| Mounting | Wall mounting | - |
| Suitable for outdoor use | Yes | - |
| Reset button | Yes | Yes |
| LED indicators | Yes | Yes |
| Market positioning | - | Portable |
| Built-in display | - | Yes |
| Display type | - | TFT |
| Display diagonal | - | 3.66 cm (1.44") |
Ethernet LAN features
Ethernet LAN features
| Ethernet LAN | Yes | No |
|---|---|---|
| Ethernet LAN interface type | Gigabit Ethernet | - |
| Networking standards | IEEE 802.3af, IEEE 802.3at | - |
| DHCP server | Yes | Yes |
| DHCP client | - | Yes |
Wireless LAN features
Wireless LAN features
| Wi-Fi | Yes | Yes |
|---|---|---|
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| WLAN data transfer rates supported | 300 Mbit/s | 867 Mbit/s |
| Wi-Fi frequency | 2.4 GHz | 5 GHz |
Mobile network
Mobile network
| Data network | 4G, 5G, LTE | 2G, 3G, 4G, LTE |
|---|---|---|
| 4G standard | LTE-TDD & LTE-FDD | LTE |
| Number of SIM cards | 2 | - |
| 2G standards | - | Edge, GPRS, GSM |
| 3G standards | - | DC-HSPA+, HSPA, UMTS |
| 2G bands supported | - | 850,900,1800,1900 MHz |
| 3G bands supported | - | 900,2100 MHz |
| 4G bands supported | - | 800,900,1800,2100 MHz |
| GSM bands supported | - | 850,900,1800,1900 MHz |
| UMTS bands supported | - | 900,2100 MHz |
| SIM card type | - | MicroSIM |
Ports & interfaces
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 | - |
|---|---|---|
| USB port | No | - |
| Card reader integrated | - | Yes |
| Compatible memory cards | - | MicroSD (TransFlash) |
Security
Security
| Security algorithms | SSH | WPA-PSK, WPA2-PSK |
|---|---|---|
| Firewall | Yes | - |
| IP address filtering | Yes | - |
| URL filtering | Yes | - |
| DMZ support | Yes | - |
| Port forwarding | Yes | - |
| VPN support | Virtual Private Network (VPN) pass-through | - |
Certificates
Certificates
| Certification | CE, WEEE, RoHS, HSF | CE, RoHS |
|---|
Packaging content
Packaging content
| Cables included | LAN (RJ-45) | Micro-USB |
|---|
Performance
Performance
| Web-based management | Yes | - |
|---|---|---|
| Management protocols | APN, PIN/PUK, MQTT | - |
| Antenna type | Internal | - |
| Antennas quantity | 6 | - |
| Antenna gain level (max) | 10 dBi | - |
| Mobile operating systems supported | Android, iOS | - |
| Windows operating systems supported | - | Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP |
Power
Power
| Power source type | PoE | AC |
|---|---|---|
| Power consumption (typical) | 16 W | - |
| Battery capacity | - | 3000 mAh |
Operational conditions
Operational conditions
| Operating temperature (T-T) | -40 - 60 °C | 0 - 35 °C |
|---|---|---|
| Storage temperature (T-T) | -40 - 65 °C | -20 - 60 °C |
| Operating relative humidity (H-H) | 5 - 95% | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 95% | 5 - 90% |
Weight & dimensions
Weight & dimensions
| Width | 255 mm | 106 mm |
|---|---|---|
| Depth | 256 mm | 66 mm |
| Height | 58 mm | 16 mm |
| Weight | 1.14 kg | - |
Packaging data
Packaging data
| Package width | 280 mm | 149 mm |
|---|---|---|
| Package depth | 420 mm | 101 mm |
| Package height | 108 mm | 60 mm |
| Package weight | 2.82 kg | 260 g |
| User guide | - | Yes |
Logistics data
Logistics data
| Country of origin | China | - |
|---|---|---|
| Products per master (outer) case | 3 pc(s) | - |
| Master (outer) case gross weight | 9.6 kg | - |
| Master (outer) case length | 535 mm | - |
| Master (outer) case width | 447 mm | - |
| Master (outer) case height | 325 mm | - |
| Harmonized System (HS) code | 85176990 | 85176990 |
